High quality chrome-plated fire extinguisher valve gauges JQ0809
Most dry-chemical fire extinguishers have a built-in pressure gauge. If the gauge indicator is pointing to "recharge," the pressure in the extinguisher may be too low to expel the contents. The National Fire Protection Association recommends having dry extinguishers inspected every six years, even if the gauge indicates correct pressure.
• Reliable, small diameter, low profile gauge
• Direct drive (no linkages or hairsprings) eliminating premature
failure from the gear and movement
• Safety over-pressure port on the lens
• "Use No Oil" for use in oxygen service
| Dial | 1” (25mm), 1.25” (32mm) or 1.5” (40mm) white aluminum with black markings |
| Case | 304 SS |
| Lens | Plexiglass or Pocarbonately |
| Spiral Tube | 60 to 2000 PSI:phosphor bronze 3000 PSI: Beryllium copper or Stainless steel
4000 PSI and above: 316L SS |
| Connection | 1/8” NPT standard, back |
| Pointer | 3000 PSI and below: Brass 4000 PSI and above: 304 SS |
| Over-Pressure Limit | 10% of full scale value |
| Working Pressure | 10% of full scale value |
| Ambient | -40°F to 150°F (-40°C to 65°C) |
| Accuracy | ±3-2-3% ANSI/ASME Grade B |
| Enclosure Rating | IP65 |
CONTACT:
Company: YUYAO JINQIANG FIRE FIGHTING EQUIPMENT FACTORY
Add: Huajia Village,Huangjiabu Town,Yuyao City,Zhejiang Province ,China
website: www.jqfire.com
Sales manager: Amy Fu
Email: jqamyfu@gmail.com
amy@jqfire.com
Tel: 0086-13858403138
FAQ:
1. Q: How can I get some samples?
A: We are honored to offer you samples for free.
2. Q: How does your factory do regarding quality control?
A: Quality is priority. Safetylife people always attach great importance to quality controlling from the very beginning to the very end.
3. Q: OEM is available?
A: Yes, we can do as our customer’s requirement, like print your own logo, model, gift box and so on.
Welcome to contact us for more details, most competitive price for you!1-12kg carbon steel empty fire extinguisher cylinder
1. Prompt response.
2. OEM & ODM is available.
3. Support factory inspection.
4. Standard qulity control system.
5. Different choices of payment and
6. Independant R&D dept, designing dept,to meet your special
7. Whole set of technical supports and with abroad projects experience.
8. We are manufacturer, offer better price better production9.Sample order, customized
Other fire extinguisher
Product Tags:
|
|
Chrome Plated Pressure Gauge Manometer , Brass Fire Extinguisher Components Images
|
